50m Low Head Kaplan Turbine Micro Hydro High Flow For Mini Hydro Station
Product Details:
| Place of Origin: | China |
| Brand Name: | Wawushan |
| Certification: | ISO9001 |
| Model Number: | ZDJP-063 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | plywood |
| Delivery Time: | 180 wordking days |
| Payment Terms: | T/T |
| Supply Ability: | 1+unit+4 months |
|
Detail Information |
|||
| Layout: | Vertical | Runner Blade: | Fixed |
|---|---|---|---|
| Runner Diameter: | 0.8 M | Water Head: | 50 M |
| Water Flow: | 3.5 M³/s | Cpacity: | 1370 KW |
| Highlight: | 50m Low Head Kaplan Turbine,Kaplan Turbine Micro Hydro High Flow,50m Kaplan Turbine Generator |
||
Product Description
Low Water Head 50m Kaplan Turbine Generator Mini Hydro Station
Our Main Products:
Francis, Kaplan, Pelton, Turgo, Tubular Turbine Generator Unit
Auxiliary Equipment:
Inlet valves (Hydraulic / electric control butterfly valves, ball valves, sluice valves), Governors, Excitations (SCR excitations, DC excitation systems, AC brushless exciters), MV/HV Switchgear, Oil pressure supply systems, control facilities, automatic control systems, Transformers, Power cable and so on.
| Place of Origin: | Sichuan, China |
| Brand Name: | Customized |
| Warranty: | 1 year |
| Application: | Hydropower Plant |
| Certificate: | ISO9001 |
| Lifetime | 35 years |
Kaplan turbine is a kind of turbine suit to low water head 3-45 meters, and with certain big flow, normally divided into fixed blades and adjustable blades turbine. Main components including: runner, draft cone, water chamber, guide vane, bearing, and main shaft. The spiral case could be steel or concrete. The runner diameter we can manufacture is from 80cm to 4meters, with rated output 50Kw to 20Mw.
Turbine units normally be vertical shaft arrangement. Generator equipped with same or different shaft, with Anyway, they will share the same rotating speed. If specially required, a speed increase gear could be equipped between turbine and generator in order to smaller the generator size.
Ø Suitable water head: 3-45m;
Ø Output scope: 100Kw -30Mw;
Ø Runner diameter: 80cm -400cm;
Ø Runner material: stainless steel;
Ø Arrangement type: Vertical;
